Hello everyone, today we will learn about the common chips in domestic mainboards

2

00:00:06,033 --> 00:00:09,733

First of all, let's take a look at some chips in the Loongson mainboard

3

00:00:11,766 --> 00:00:15,500

In this mainboard, this is Loongson's 3A4000

4

00:00:19,966 --> 00:00:23,466

There are four inductors that are the core power supply circuit of the CPU,

5

00:00:23,633 --> 00:00:26,166

and the voltage value is 1.25V

6

00:00:27,733 --> 00:00:34,400

There are several DrMOS controllers next to it, controlled by the main chip MP2978

7

00:00:38,833 --> 00:00:42,833

The model of these DRMOS chips is MP8690

8

00:00:44,233 --> 00:00:49,300

There is an independent power supply which is 1.29V, which is for the CPU

9

00:00:49,933 --> 00:00:55,033

There is also a 1.2V power supply next to it, which is also for the CPU

10

00:00:55,500 --> 00:00:58,766

These are the three power supplies required by the CPU

11

00:01:00,766 --> 00:01:06,600

There are several LDO power supply chips such as UP8801S on the back of the mainboard

12

00:01:07,066 --> 00:01:09,000

Let's take a look at its pin definition

13

00:01:09,200 --> 00:01:17,266

Pin 1 is POK, pin 2 is EN, pin 3 is VIN power supply input, pin 4 VCNTL is the power supply

14

00:01:17,966 --> 00:01:24,366

Pin 5 is NC, pin 6 is OUT output, pin 7 is feedback, pin 8 is grounding

15

00:01:27,666 --> 00:01:32,733

After the measurement, we know that this is a 1.23V LDO

16

00:01:33,833 --> 00:01:36,900

This is a 1.78V LDO

17

00:01:37,100 --> 00:01:44,033

Here these are 1.14V, 1.1V and 1.0V standby LDO power supplies

18

00:01:44,733 --> 00:01:46,333

This is the network card chip

19

00:01:47,500 --> 00:01:52,366

There are two UP8801S at this position and this side of the mainboard,

20

00:01:53,233 --> 00:01:55,666

they are also LDO power supply chips

21

00:01:56,900 --> 00:02:02,800

This one is 1.19V, the one above is 3.3V SB standby voltage

22

00:02:03,666 --> 00:02:09,800

There are several PWM chips of the model UP1727, which integrate MOS tubes

23

00:02:12,466 --> 00:02:17,866

This is 1.8V, this is 1.1V, this is 1.05V

24

00:02:18,366 --> 00:02:21,866

This is a 1.5V DDR3 memory power supply

25

00:02:22,433 --> 00:02:24,833

Next, here is a PWM circuit

26

00:02:25,133 --> 00:02:28,366

This is the main power supply of the memory 1.2V,

27

00:02:29,366 --> 00:02:33,466

which is generated by the control of the chip UP1537

28

00:02:34,066 --> 00:02:36,866

Here are several LDO linear power supplies

29

00:02:39,700 --> 00:02:45,933

One of them is used to control the generation of the VTT power supply of the video memory, 0.75V

30

00:02:46,800 --> 00:02:52,300

This one is used to control the generation of VTT power supply of the memory, 0.6V

31

00:02:53,366 --> 00:02:56,633

There is a set of MP8633 next to it,

32

00:02:56,900 --> 00:03:01,066

which is used to generate 2.5V VPP power supply for the memory

33

00:03:02,300 --> 00:03:04,333

Here are some other functional chips

34

00:03:05,533 --> 00:03:11,866

For example, this is an 8-bit high-speed video digital-to-analog converter with VGA interface,

35

00:03:12,500 --> 00:03:17,533

which is connected to the PCH, and the display signal is output by the PCH

36

00:03:19,100 --> 00:03:22,566

This is the signal conversion chip of the HDMI interface,

37

00:03:22,733 --> 00:03:27,366

which is also connected to the PCH, and the display signal is output by the PCH

38

00:03:27,666 --> 00:03:31,633

After conversion by this chip, it is sent to the HDMI interface

39

00:03:32,333 --> 00:03:34,833

Here is a USB3.0 controller

40

00:03:35,766 --> 00:03:40,500

There is a flash chip next to it, which is the program of the USB3.0 chip

41

00:03:41,733 --> 00:03:46,166

This is a 25Q64, with an 8MB main BIOS

42

00:03:46,766 --> 00:03:49,300

The following part is the audio circuit

43

00:03:50,133 --> 00:03:51,966

The one in the middle is the memory

44

00:03:52,333 --> 00:03:53,466

this is a clock chip

45

00:03:56,833 --> 00:03:59,966

This is an EC, and there is a flash chip next to it

46

00:04:03,966 --> 00:04:07,066

This is a SATA 3.0 controller

47

00:04:08,866 --> 00:04:13,266

It also has a flash chip hanging on the side, with independent programs

48

00:04:18,033 --> 00:04:24,866

This is a USB3.0 control chip, mainly used to control the USB3.0 interface on the front panel

49

00:04:26,266 --> 00:04:28,800

It also has a flash chip with the program

50

00:04:35,900 --> 00:04:39,300

Let's take a look at the introduction of the Phytium mainboard

51

00:04:41,366 --> 00:04:45,533

This Phytium mainboard does not have a graphics card function inside the CPU,

52

00:04:47,666 --> 00:04:51,133

it must be connected to an independent graphics card to display

53

00:04:51,966 --> 00:04:56,533

This PCIE 16X slot is used to insert a discrete graphics card,

54

00:04:56,900 --> 00:04:59,900

and there are two PCIE 8X slots next to it

55

00:05:02,066 --> 00:05:05,700

This M.2 interface is used to insert solid-state drives

56

00:05:06,000 --> 00:05:07,633

Below is the audio circuit

57

00:05:07,933 --> 00:05:09,233

This is a BIOS chip

58

00:05:13,500 --> 00:05:18,733

Here is the SATA controller, dedicated to managing these SATA interfaces

59

00:05:19,233 --> 00:05:24,266

This is a chip for the clock, gate array, and RTC, which is a logic chip

60

00:05:29,833 --> 00:05:32,900

Here is the memory power supply and the CPU power supply circuit

61

00:05:33,166 --> 00:05:36,233

The power consumption of this power supply is relatively small,

62

00:05:36,466 --> 00:05:39,266

and the power supply circuit has only one power supply

63

00:05:39,766 --> 00:05:42,766

There is an IO chip and a level conversion chip here

64

00:05:46,233 --> 00:05:51,600

Here is the Hub master chip of USB3.0 and the Hub chip of USB2.0

65

00:05:53,800 --> 00:05:56,800

There is also a USB3.0 master chip

66

00:05:59,066 --> 00:06:01,733

Ok, here are some common chips on this mainboard
