iPhone audio circuit repairing

2

00:00:02,866 --> 00:00:08,733

This video mainly explains how to find the earpiece and bottom speaker signal of iPhone 12 and 12Pro models

3

00:00:10,400 --> 00:00:15,533

Search method step 1, find the handset or charging connector in the component map,

4

00:00:15,600 --> 00:00:17,633

and confirm the position number

5

00:00:19,333 --> 00:00:23,400

Step 2, search for the position number in the circuit diagram

6

00:00:25,466 --> 00:00:30,666

Step 3, after finding the connector, check the pin identification of the connector

7

00:00:31,900 --> 00:00:36,633

The signal marked SPKRAMP means the signal of the earpiece or speaker

8

00:00:38,533 --> 00:00:42,666

Step 4, jump to the bitmap to view the connected components

9

00:00:43,533 --> 00:00:48,200

The voltage and diode value of the signal can be measured at the position of the yellow point in the bitmap

10

00:00:48,966 --> 00:00:56,033

When checking the maps, first open the component maps, circuit diagrams, and bitmaps of iPhone12 and 12Pro

11

00:00:57,433 --> 00:01:02,200

First, find the data signal from the earpiece connector to the earpiece amplifier

12

00:01:02,600 --> 00:01:06,733

Find the earpiece connector in the component map and confirm the position number,

13

00:01:08,800 --> 00:01:11,866

then search for the position number in the schematic diagram

14

00:01:12,733 --> 00:01:18,900

After finding the connector, the pin marked SPKRAMP represents the signal of the earpiece speaker

15

00:01:19,600 --> 00:01:23,400

Pins 19 and 21 of the connector are the handset data negative

16

00:01:24,100 --> 00:01:26,000

Jump to the bitmap according to the name,

17

00:01:26,566 --> 00:01:31,233

and the data negative is directly connected to the earpiece amplifier U8100

18

00:01:32,700 --> 00:01:36,366

Pins 20 and 22 of the connector are positive data of the handset

19

00:01:36,866 --> 00:01:42,000

Jump to the bitmap according to the name, the data is also directly connected to the earpiece amplifier,

20

00:01:42,233 --> 00:01:43,733

without fuse in the middle

21

00:01:44,500 --> 00:01:48,166

Pin 23 of the connector is the negative voltage detection of the data

22

00:01:48,633 --> 00:01:54,700

Jump to the bitmap according to the name, the data negative is connected to the fuse resistor R11024,

23

00:01:55,100 --> 00:01:58,900

and connected to the earpiece amplifier after passing through the resistor

24

00:01:59,533 --> 00:02:03,566

Pin 24 of the connector is the positive voltage detection of the handset data

25

00:02:03,800 --> 00:02:09,266

Jump to the bitmap according to the name, the pin is connected to the resistor R11021,

26

00:02:09,800 --> 00:02:14,333

and after the resistor is connected to the earpiece amplifier U8100

27

00:02:15,600 --> 00:02:19,666

If there is no sound from the earpiece when playing a song or making a call,

28

00:02:19,966 --> 00:02:22,066

we need to find the corresponding signals

29

00:02:23,433 --> 00:02:25,966

If the signal value is found to be abnormal,

30

00:02:26,066 --> 00:02:30,166

we check the connected components according to the diagram to rule out damage

31

00:02:31,733 --> 00:02:36,366

Let's find the bottom speaker signal from the charging connector to the speaker amplifier

32

00:02:37,833 --> 00:02:42,733

First find the charging connector in the component map, and confirm the position number

33

00:02:44,933 --> 00:02:48,933

Then search for the position number of the charging connector in the schematic diagram

34

00:02:49,233 --> 00:02:55,233

After finding the connector, the pin marked SPKRAMP represents the signal of the bottom speaker

35

00:02:57,433 --> 00:03:01,300

Pin 39 of the connector is the data negative of the bottom speaker

36

00:03:01,766 --> 00:03:03,566

Jump to the bitmap according to the name,

37

00:03:04,000 --> 00:03:08,500

and the data negative is directly connected to the speaker amplifier U8000

38

00:03:08,933 --> 00:03:12,566

Pin 40 of the connector is the data positive of the bottom speaker

39

00:03:13,066 --> 00:03:19,800

Jump to the bitmap according to the name, the data is also directly connected to the speaker amplifier U8000

40

00:03:21,133 --> 00:03:25,533

Pin 37 of the connector is the data negative voltage detection of the bottom speaker

41

00:03:26,333 --> 00:03:31,900

Jump to the bitmap according to the name, the pin is connected to the fuse resistor R11280,

42

00:03:32,666 --> 00:03:37,933

and after passing through the resistor, it is connected to the speaker amplifier U8000

43

00:03:39,800 --> 00:03:44,266

Pin 38 of the connector is the data positive voltage detection of the bottom speaker

44

00:03:45,500 --> 00:03:50,933

Jump to the bitmap according to the name, the signal is connected to the resistor R11282,

45

00:03:52,000 --> 00:03:56,433

and after passing through the resistor, it is connected to the speaker amplifier

46

00:03:58,033 --> 00:04:01,400

If there is no sound from the bottom speaker when playing a song,

47

00:04:01,800 --> 00:04:03,766

we need to find the corresponding signal

48

00:04:04,333 --> 00:04:06,133

If the measured value is abnormal,

49

00:04:06,400 --> 00:04:10,533

we can check the connected components according to the diagrams to rule out damage

50

00:04:11,500 --> 00:04:13,066

That's all for this video
