iPhone audio circuit repairing

2

00:00:02,733 --> 00:00:08,433

This video mainly explains how to find the earpiece and bottom speaker signal of iPhone 12 Pro Max

3

00:00:10,533 --> 00:00:15,566

Search method step 1, find the handset or charging connector in the component map,

4

00:00:15,633 --> 00:00:17,600

and confirm the position number

5

00:00:18,600 --> 00:00:22,566

Step 2, search for the position number in the circuit diagram

6

00:00:25,633 --> 00:00:31,133

Step 3, after finding the connector, check the pin identification of the connector

7

00:00:32,000 --> 00:00:36,966

The signal marked SPKRAMP means the signal of the earpiece or speaker

8

00:00:39,133 --> 00:00:43,433

Step 4, jump to the bitmap to view the connected components

9

00:00:44,600 --> 00:00:49,566

The voltage and diode value of the signal can be measured at the position of the yellow point in the bitmap

10

00:00:50,900 --> 00:00:57,000

When checking the maps, first open the iPhone 12Pro Max component map, circuit diagram, and bitmap

11

00:00:57,766 --> 00:01:02,300

First, find the data signal from the earpiece connector to the earpiece amplifier

12

00:01:03,333 --> 00:01:07,466

Find the earpiece connector in the component map and confirm the position number,

13

00:01:11,833 --> 00:01:14,900

then search for the position number in the schematic diagram

14

00:01:15,966 --> 00:01:22,266

After finding the connector, the pin marked SPKRAMP represents the signal of the earpiece speaker

15

00:01:23,000 --> 00:01:27,100

Pins 19 and 21 of the connector are the handset data negative

16

00:01:27,566 --> 00:01:29,800

Jump to the bitmap according to the name,

17

00:01:30,000 --> 00:01:35,300

the data negative is directly connected to the earpiece amplifier U8100

18

00:01:36,100 --> 00:01:40,033

Pins 20 and 22 of the connector are positive data of the handset

19

00:01:40,233 --> 00:01:45,733

Jump to the bitmap according to the name, the data is also directly connected to the earpiece amplifier,

20

00:01:45,833 --> 00:01:47,400

without fuse in the middle

21

00:01:47,866 --> 00:01:51,733

Pin 23 of the connector is the negative voltage detection of the data

22

00:01:52,266 --> 00:01:58,966

Jump to the bitmap according to the name, the data negative is connected to the fuse resistor R11024,

23

00:01:59,533 --> 00:02:03,633

and connected to the earpiece amplifier after passing through the resistor

24

00:02:05,166 --> 00:02:09,366

Pin 24 of the connector is the positive voltage detection of the handset data

25

00:02:09,866 --> 00:02:15,733

Jump to the bitmap according to the name, the pin is connected to the resistor R11021,

26

00:02:16,500 --> 00:02:21,633

and after the resistor it is connected to the earpiece amplifier U8100

27

00:02:21,966 --> 00:02:26,033

If there is no sound from the earpiece when playing a song or answering a call,

28

00:02:26,366 --> 00:02:28,533

we need to find the corresponding signals

29

00:02:29,833 --> 00:02:32,433

If the signal value is found to be abnormal,

30

00:02:32,600 --> 00:02:36,700

we check the connected components according to the diagram to rule out damage

31

00:02:38,200 --> 00:02:42,933

Let's find the bottom speaker signal from the charging connector to the speaker amplifier

32

00:02:43,866 --> 00:02:48,600

First find the charging connector in the component map, and confirm the position number

33

00:02:49,833 --> 00:02:53,966

Then search for the position number of the charging connector in the schematic diagram

34

00:02:54,433 --> 00:03:00,633

After finding the connector, the pin marked SPKRAMP represents the signal of the bottom speaker

35

00:03:02,666 --> 00:03:06,766

Pins 7 and 9 of the connector are the data positive of the bottom speaker

36

00:03:07,033 --> 00:03:12,566

Jump to the bitmap according to the name, the data is connected to the speaker amplifier U8000

37

00:03:13,600 --> 00:03:17,233

Pin 5 of the connector is the data positive voltage detection signal

38

00:03:17,666 --> 00:03:23,600

Jump to the bitmap according to the name, the pin is connected to the fuse resistor R11282,

39

00:03:24,700 --> 00:03:30,266

and after passing through the resistor, it is connected to the speaker amplifier U8000

40

00:03:30,733 --> 00:03:34,666

Pins 10 and 12 of the connector are the data negative of the speaker

41

00:03:35,566 --> 00:03:37,433

Jump to the bitmap according to the name,

42

00:03:37,933 --> 00:03:42,000

the data negative is connected to the speaker amplifier, without fuse in the middle

43

00:03:42,766 --> 00:03:45,766

Pin 8 of the connector is the negative voltage detection

44

00:03:47,633 --> 00:03:53,533

Jump to the bitmap according to the name, the pin is connected to the fuse resistor R11280,

45

00:03:54,800 --> 00:03:59,233

and after passing through the resistor, it is connected to the speaker amplifier

46

00:03:59,566 --> 00:04:03,633

If there is no sound from the earpiece when playing a song or answering a call,

47

00:04:03,966 --> 00:04:06,066

we need to find the corresponding signals

48

00:04:06,933 --> 00:04:09,533

If the signal value is found to be abnormal,

49

00:04:09,833 --> 00:04:13,866

we check the connected components according to the diagram to rule out damage

50

00:04:14,600 --> 00:04:16,333

That's all for this video
