1

00:00:00,600 --> 00:00:04,266

In this lesson, let's learn the maintenance steps of no touch faults

2

00:00:05,600 --> 00:00:10,900

When repairing no touch, first replace a display screen to rule out whether it is a screen problem

3

00:00:13,400 --> 00:00:18,633

Because the display contains a touch screen, we directly replace it with a good display

4

00:00:21,400 --> 00:00:24,433

After replacing the screen, if the touch is normal,

5

00:00:24,766 --> 00:00:28,166

it means that the touch screen is damaged and the touch fails

6

00:00:31,666 --> 00:00:34,200

Replacing a good screen fixes the problem

7

00:00:35,933 --> 00:00:37,933

There will also be such a situation,

8

00:00:38,233 --> 00:00:42,800

that is, after replacing the screen, the touch screen still does not respond

9

00:00:43,533 --> 00:00:47,600

We can confirm that this is caused by a circuit failure on the mainboard

10

00:00:48,300 --> 00:00:50,600

At this point we are going to the next step

11

00:00:56,166 --> 00:01:01,966

Find the touch connector on the mainboard and measure the diode value of the pins related to the touch circuit

12

00:01:06,800 --> 00:01:11,000

When measuring the ground value, the multimeter is set to the diode range,

13

00:01:11,100 --> 00:01:14,866

the red marker is grounded, and the black marker is used to measure

14

00:01:15,233 --> 00:01:19,333

We need to measure the diode value of power supply and signal

15

00:01:20,000 --> 00:01:24,600

Next, I will take Xiaomi 11 as an example to demonstrate

16

00:01:29,033 --> 00:01:31,400

We first need to find the touch connector

17

00:01:33,133 --> 00:01:35,300

Enter TP_RESET to search

18

00:01:37,466 --> 00:01:41,133

If we cannot find it, we search for another code starting with TS

19

00:01:44,400 --> 00:01:46,200

This way we can find the touch circuit

20

00:01:47,933 --> 00:01:51,033

TS is touch, TP is also touch

21

00:01:54,400 --> 00:01:56,200

This is the code name for reset

22

00:01:56,966 --> 00:02:02,166

If you find the touch reset, you can find the touch connector J6503

23

00:02:02,966 --> 00:02:04,866

That's all for this lesson
