1

00:00:01,000 --> 00:00:05,900

This lesson talks about the maintenance of abnormal charging of Android mobile phones,

2

00:00:06,333 --> 00:00:08,333

mainly from four aspects

3

00:00:09,000 --> 00:00:11,966

The first is no charging icon maintenance

4

00:00:12,700 --> 00:00:15,766

Second, abnormal battery maintenance

5

00:00:16,300 --> 00:00:19,466

Third, abnormal temperature maintenance

6

00:00:21,300 --> 00:00:24,033

Fourth, low battery maintenance

7

00:00:25,366 --> 00:00:28,600

First look at how to repair no charging icon

8

00:00:30,366 --> 00:00:34,733

Let's take a look at the normal mobile phone charging phenomenon

9

00:00:35,033 --> 00:00:39,333

Normally, there will be a prompt when the mobile phone is charging.

10

00:00:40,366 --> 00:00:44,366

For example, the current mobile phone prompts a circle

11

00:00:44,933 --> 00:00:50,833

Some hints are that there will be a lightning icon in the upper right corner or the phone will vibrate

12

00:00:53,600 --> 00:00:56,933

These are normal mobile phone charging phenomena

13

00:00:57,866 --> 00:01:00,933

That abnormal cell phone is the opposite

14

00:01:01,400 --> 00:01:05,633

After plugging in and charging, there is no prompt on the phone interface,

15

00:01:05,800 --> 00:01:09,166

no vibration, and no charging icon is displayed

16

00:01:09,933 --> 00:01:14,800

It is in the upper right corner where the charging icon is generally not displayed

17

00:01:15,366 --> 00:01:19,233

There is no difference between a mobile phone and a charging cable

18

00:01:19,733 --> 00:01:22,633

This is the failure without charging icon

19

00:01:24,066 --> 00:01:27,000

Next, look at the charging process

20

00:01:27,566 --> 00:01:30,833

The charging process is that when we plug in the charger,

21

00:01:31,333 --> 00:01:36,600

the data cable will have a 5V power supply to the small board at the end of the phone

22

00:01:39,600 --> 00:01:44,600

This power is supplied to the overvoltage protection circuit on the motherboard

23

00:01:45,466 --> 00:01:51,666

The overvoltage protection circuit recognizes that the power supply is normal and lets it pass

24

00:01:52,166 --> 00:01:56,766

After passing, it provides power to the charging chip on the motherboard

25

00:01:57,366 --> 00:02:04,200

After the charging chip adjusts the 5V voltage, it will output power to the battery to charge the battery

26

00:02:05,966 --> 00:02:12,566

The CPU detects the charging power information through the bus and controls the work of the charging chip

27

00:02:13,966 --> 00:02:18,700

Which circuits are related to the unresponsiveness of plugging in the charger?

28

00:02:19,233 --> 00:02:24,700

It is related to the channel of the 5V power supply, there are data lines, chargers,

29

00:02:24,700 --> 00:02:28,766

and the lines on the small board of the tail plug or the tail plug cable

30

00:02:29,633 --> 00:02:32,033

If the tail plug cable is damaged,

31

00:02:32,300 --> 00:02:37,900

it will also cause the 5V power supply to fail to supply the overvoltage protection chip

32

00:02:38,600 --> 00:02:43,500

In the same way, if the overvoltage protection circuit on the main board fails,

33

00:02:43,500 --> 00:02:47,966

the 5V power supply cannot be supplied to the charging chip internally

34

00:02:48,766 --> 00:02:55,333

If there is no abnormality in the overvoltage protection circuit and there is an abnormality in the charging chip,

35

00:02:55,833 --> 00:03:00,166

it will not be able to step down the 5V power supply to the battery

36

00:03:00,733 --> 00:03:06,033

If there is no problem with the charging chip, the CPU loses control of the charging chip,

37

00:03:06,033 --> 00:03:11,066

causing the charging chip to not work, which will also cause a failure of no charging

38

00:03:12,800 --> 00:03:17,400

The related circuits that lead to non-charging are the data line, the charger,

39

00:03:17,400 --> 00:03:23,400

the tail plug cable, the overvoltage protection circuit on the motherboard, the circuit of the charging chip,

40

00:03:23,766 --> 00:03:27,200

and the circuit controlled by the CPU through the bus

41

00:03:28,766 --> 00:03:34,200

Only these 6 items need to be considered if there is no response to plugging and charging

42

00:03:34,733 --> 00:03:36,666

That's all for this lesson
