iPhone audio circuit repairing

2

00:00:03,366 --> 00:00:08,066

In this lesson we're going to learn how to find the I2S audio bus from the CPU to the baseband

3

00:00:08,066 --> 00:00:09,933

of the iPhone 12 Pro Max

4

00:00:11,800 --> 00:00:16,966

After the bus has a problem, it will cause no handset and no transmission failure

5

00:00:17,500 --> 00:00:23,633

Search method step 1, find the baseband chip in the component map and confirm the position number

6

00:00:25,033 --> 00:00:29,033

Step 2, search for the position number in the circuit diagram

7

00:00:29,733 --> 00:00:34,000

Step 3, after finding the baseband, check the pins

8

00:00:35,066 --> 00:00:39,433

I2S is the audio bus from the CPU to the baseband when making a call

9

00:00:40,366 --> 00:00:45,800

Step 4, jump to the bitmap according to the pin, and view the connected components

10

00:00:46,100 --> 00:00:50,066

The diode value can be measured at the position of the yellow point in the bitmap

11

00:00:51,233 --> 00:00:57,500

When checking the maps, first open the iPhone 12 Pro Max component map, circuit diagram, and bitmap

12

00:00:58,133 --> 00:01:02,833

Find the baseband chip in the component map and confirm the position number

13

00:01:03,433 --> 00:01:06,666

Then search for the position number in the schematic diagram

14

00:01:07,400 --> 00:01:10,200

Because the baseband has many solder points,

15

00:01:11,033 --> 00:01:14,933

to prevent mistakes when searching, we click Advanced Search

16

00:01:15,566 --> 00:01:20,866

After clicking Advanced Search, there will be a list about the pages of the baseband chip

17

00:01:21,400 --> 00:01:23,100

Let's view them in turn

18

00:01:24,233 --> 00:01:30,833

In the list, the pin of the baseband chip marked with I2S represents the audio bus from the CPU to the baseband

19

00:01:31,833 --> 00:01:34,900

Pin AF30 of the baseband chip is the detection clock

20

00:01:36,166 --> 00:01:38,233

Jump to the bitmap according to the name,

21

00:01:38,500 --> 00:01:42,433

the detection clock is connected to the CPU through the middle connection point

22

00:01:43,033 --> 00:01:46,433

Pin AF32 is the data output of the I2S bus

23

00:01:47,966 --> 00:01:49,800

Jump to the bitmap according to the name,

24

00:01:50,366 --> 00:01:54,466

the data output pin is connected to the CPU through the middle connection point

25

00:01:55,066 --> 00:01:59,300

Pin AG31 of the baseband chip is the data input

26

00:01:59,533 --> 00:02:00,666

Jump to the bitmap,

27

00:02:01,066 --> 00:02:04,433

the pin is connected to the CPU through the middle connection point

28

00:02:05,666 --> 00:02:09,166

Pin AH30 is the serial clock of the I2S bus

29

00:02:09,533 --> 00:02:11,400

Jump to the bitmap according to the name,

30

00:02:11,866 --> 00:02:15,633

the serial clock is connected to the CPU through the middle connection point

31

00:02:16,166 --> 00:02:20,066

If there is no handset and no call failure after the iPhone is dropped,

32

00:02:20,900 --> 00:02:25,900

it is mostly because the I2S bus between the baseband and the CPU is disconnected

33

00:02:26,300 --> 00:02:29,300

We can measure the diode value of the I2S bus

34

00:02:30,566 --> 00:02:36,500

If the value is normal, we only need to reball the tin to fix the failure of no transmission and no handset

35

00:02:37,433 --> 00:02:39,133

That's all for this video
