iPhone connection circuit repairing
2
00:00:02,833 --> 00:00:06,100
This video mainly explains the working principle of the connection circuit
3
00:00:06,133 --> 00:00:08,900
of iPhone XR to iPhone 11 Pro Max models
4
00:00:11,066 --> 00:00:17,566
In the functional block diagram, the main power supply, CPU, USB chip, ACC power supply chip,
5
00:00:17,600 --> 00:00:20,133
and the charging connector form the connection circuit
6
00:00:20,800 --> 00:00:24,566
Working principle step 1, after the iPhone is triggered,
7
00:00:25,200 --> 00:00:29,700
the main power supply will provide 1.8V and 3.0V power supply for the USB chip
8
00:00:29,766 --> 00:00:31,700
after receiving the power-on signal
9
00:00:32,366 --> 00:00:38,533
Step 2, after the CPU works normally, it will detect the USB chip through the I2C bus,
10
00:00:39,366 --> 00:00:42,500
and the iPhone will enter the system after the detection is passed.
11
00:00:42,666 --> 00:00:47,566
Step 3, when copying the iPhone data, we plug in the data cable,
12
00:00:48,633 --> 00:00:54,300
and the data cable insertion detection signal DETECT will be sent to the USB chip through the charging connector
13
00:00:54,666 --> 00:00:58,600
Step 4, after the USB chip receives the DETECT signal,
14
00:00:59,000 --> 00:01:03,233
it will send the data line ID identification signal to the main power supply
15
00:01:04,166 --> 00:01:08,133
Step 5, after the main power supply receives the ID signal,
16
00:01:08,333 --> 00:01:11,300
it will send an identification signal to the CPU
17
00:01:12,133 --> 00:01:16,066
The CPU controls the ACC power supply chip through the I2C bus
18
00:01:16,066 --> 00:01:19,500
to generate ACC power supply and send it to the USB chip
19
00:01:21,166 --> 00:01:25,133
Step 6, after the USB chip receives the ACC power supply,
20
00:01:26,166 --> 00:01:29,633
it will convert ACC1 and ACC2 power supplies,
21
00:01:29,866 --> 00:01:32,900
and send them to the data line through the charging connector
22
00:01:33,933 --> 00:01:39,133
ACC1 and ACC2 are the power supply voltages on the front and back of the data line
23
00:01:39,733 --> 00:01:43,000
Step 7, after the data line has power supply,
24
00:01:43,266 --> 00:01:47,366
it will send the verification information of the computer connection to the USB chip
25
00:01:47,433 --> 00:01:49,733
through the DP1 and DP2 buses
26
00:01:50,033 --> 00:01:56,700
Step 8, after the USB chip receives the connection information, it sends an interrupt signal to the CPU
27
00:01:58,233 --> 00:02:01,766
Step 9, after the CPU receives the interrupt signal,
28
00:02:02,066 --> 00:02:05,300
it will read the connection information through the UART bus
29
00:02:06,633 --> 00:02:11,966
After the verification information is read, the "Add Trust" prompt will pop up on the screen
30
00:02:13,233 --> 00:02:17,933
After clicking Trust, it will pop up a prompt to enter the screen unlock password
31
00:02:18,366 --> 00:02:22,666
When we enter the password, the iPhone and computer can establish a connection
32
00:02:23,600 --> 00:02:26,600
Step 10, when copying data on the computer,
33
00:02:27,200 --> 00:02:32,366
the CPU will read the data stored in the hard disk and send it to the USB chip through the USB bus
34
00:02:33,533 --> 00:02:37,200
Step 11, after the USB chip receives the data,
35
00:02:38,600 --> 00:02:42,233
it sends it to the data line through the DP1 and DP2 buses,
36
00:02:42,700 --> 00:02:44,600
and then sends it to the computer
37
00:02:45,533 --> 00:02:49,833
At this time, the progress of copying data will be displayed on the computer
38
00:02:50,333 --> 00:02:53,100
If there is no response when we plug in the data cable,
39
00:02:53,400 --> 00:02:55,833
it means that the connection circuit is faulty
40
00:02:56,400 --> 00:02:58,766
First, we can replace the USB chip
41
00:02:59,800 --> 00:03:04,600
If it is still not normal after replacement, we check the working conditions of the USB chip
42
00:03:05,133 --> 00:03:06,666
That's all for this video
