In this lesson, let's take a look at the standby 3V generation process of different brands of mainboards

2

00:00:06,366 --> 00:00:10,100

Here are only the three mainboards that we repair the most

3

00:00:10,500 --> 00:00:12,566

Gigabyte first

4

00:00:12,700 --> 00:00:18,400

Gigabyte generally has two voltage regulator tubes, and their appearance is not the same

5

00:00:18,866 --> 00:00:23,566

The regulator tube on the left is generally used to generate the deep sleep standby voltage

6

00:00:23,900 --> 00:00:29,166

The voltage regulator tube on the right is generally used to generate the main standby 3V voltage

7

00:00:29,733 --> 00:00:31,300

ASUS is next

8

00:00:31,500 --> 00:00:33,600

Most of ASUS is relatively simple,

9

00:00:33,766 --> 00:00:36,966

that is, the main standby and deep sleep standby voltages are generated

10

00:00:36,966 --> 00:00:39,966

after the purple 5V passes through a voltage regulator tube.

11

00:00:40,300 --> 00:00:42,266

The two of them are connected

12

00:00:43,700 --> 00:00:45,466

The most complex is the MSI

13

00:00:46,000 --> 00:00:51,566

First, the purple 5V will generate a deep sleep standby voltage through an eight-pin LDO chip

14

00:00:52,000 --> 00:00:57,200

Then, this deep sleep standby voltage will power PCH and IO

15

00:00:59,666 --> 00:01:06,266

PCH sends SLP_SUS# to control another LDO circuit or PWM circuit to generate main standby 3V

16

00:01:08,166 --> 00:01:12,866

The PCIE B10 pin is generally connected to the main standby 3V

17

00:01:13,766 --> 00:01:18,000

Although the standby 3V workflow of these three companies is listed here,

18

00:01:18,133 --> 00:01:21,366

it does not mean that the circuit must be like this

19

00:01:21,766 --> 00:01:24,866

Gigabyte, ASUS, MSI, each of them has many series

20

00:01:24,933 --> 00:01:28,700

Different series of circuit design may be different

21

00:01:28,966 --> 00:01:31,433

Here is just to tell you the usual situation
