Hello everyone, in the last class we looked at the working conditions of DDR3 memory

2

00:00:04,600 --> 00:00:08,066

In this lesson, let's take a look at the working conditions of DDR4 memory

3

00:00:08,533 --> 00:00:12,466

The first is VDDQ, the memory main power supply

4

00:00:12,900 --> 00:00:16,333

Its voltage is 1.2V

5

00:00:16,500 --> 00:00:22,366

It is better to measure it at the memory power supply inductance

6

00:00:22,600 --> 00:00:24,600

Next is the VPP

7

00:00:25,000 --> 00:00:30,966

VPP is an extra voltage of DDR4 memory, and its voltage value is 2.5V

8

00:00:31,400 --> 00:00:39,600

This voltage can be measured on pins 142, 143, 286, 287 and 288 of the memory slot

9

00:00:40,200 --> 00:00:42,500

So where are these pins?

10

00:00:42,866 --> 00:00:44,866

Let's take a look at this memory slot

11

00:00:45,200 --> 00:00:48,666

We must first distinguish between upper and lower

12

00:00:49,366 --> 00:00:52,766

In general, those near the South Bridge are down,

13

00:00:52,933 --> 00:00:55,300

and those far away from the South Bridge are up.

14

00:00:55,600 --> 00:00:59,966

The pin division of DDR4 memory is from top to bottom

15

00:01:01,366 --> 00:01:07,333

It has 144 pins on one side, and a total of 288 on both sides

16

00:01:07,600 --> 00:01:15,366

The power supply of VPP is at pins 142, 143, 286, 287 and 288, all of which are below

17

00:01:17,133 --> 00:01:20,533

We can measure directly on 288 pins

18

00:01:20,900 --> 00:01:23,366

Next is the VTT power supply

19

00:01:24,133 --> 00:01:27,933

The VTT power supply of DDR4 memory is also half of VDDQ

20

00:01:28,366 --> 00:01:31,133

VDDQ is 1.2V, then VTT is 0.6V

21

00:01:32,066 --> 00:01:37,533

It can be measured on pin 77 and pin 221 of the memory slot

22

00:01:38,866 --> 00:01:41,133

We take the anti-fool gate as the boundary,

23

00:01:41,266 --> 00:01:45,400

and the ones next to the anti-fool gate are 77 pins and 221 pins

24

00:01:45,500 --> 00:01:48,400

We can measure it directly here

25

00:01:49,700 --> 00:01:51,733

The next is reference voltage

26

00:01:52,066 --> 00:01:56,666

The reference voltage is the same as the VTT voltage, 0.6V

27

00:01:57,066 --> 00:02:04,200

It can be measured from memory to pin 146, which is the second pin from top to bottom on the right

28

00:02:04,766 --> 00:02:06,566

Next SPD power supply

29

00:02:07,000 --> 00:02:13,133

DDR4SPD power supply has two voltages, some mainboards use VPP power supply, 2.5V,

30

00:02:13,466 --> 00:02:15,833

such as Gigabyte

31

00:02:16,533 --> 00:02:19,866

Of course, more mainboards use 3.3V

32

00:02:20,133 --> 00:02:23,800

It can be measured on pin 284 of the memory slot

33

00:02:24,466 --> 00:02:28,700

Further down, the SM bus, it needs to have a waveform

34

00:02:28,900 --> 00:02:35,133

But if there is no oscilloscope, we can measure the voltage, a voltage of about 3.3V is enough

35

00:02:36,266 --> 00:02:40,900

It can be measured on 141 pins and 285 pins

36

00:02:42,000 --> 00:02:43,866

The last one, memory reset

37

00:02:43,866 --> 00:02:47,100

The memory reset is on pin 58 of the memory slot

38

00:02:47,200 --> 00:02:49,400

This pin is hard to find

39

00:02:49,766 --> 00:02:52,900

It is pulled up by the memory main power supply VDDQ

40

00:02:53,000 --> 00:02:58,233

We use a multimeter to measure, and we should be able to measure a voltage of 1.2V

41

00:02:58,700 --> 00:03:05,700

If these conditions are met, then we need to check whether the memory slot has oxidized pins

42

00:03:08,666 --> 00:03:13,366

Install the CPU at the same time, and measure whether the data lines are connected

43

00:03:13,700 --> 00:03:16,766

The above is the maintenance process of DDR4 memory
