1

00:00:02,366 --> 00:00:07,133

Hello everyone, in this lesson we will talk about the installation of Windows system on Apple computers

2

00:00:07,900 --> 00:00:11,966

Apple computer installation of Windows system is divided into two parts

3

00:00:12,266 --> 00:00:15,900

That is, Apple computer with dual system and Apple computer with single Windows system

4

00:00:16,100 --> 00:00:19,166

In fact, they are installed in the same way

5

00:00:19,666 --> 00:00:25,200

There is a very important note when installing the Windows system on an Apple computer.

6

00:00:25,366 --> 00:00:30,366

That is, only Apple computers using Intel CPUs can install Windows systems.

7

00:00:31,266 --> 00:00:38,500

Apple CPUs like M1 and M2 cannot be installed with a Windows system unless a virtual machine is used

8

00:00:39,400 --> 00:00:43,966

First of all, let's look at the Apple computer with dual systems

9

00:00:44,300 --> 00:00:49,533

Apple computer with dual system can be installed using its own boot conversion assistant

10

00:00:49,866 --> 00:00:51,900

Boot Camp Assistant is also called bootcamp

11

00:00:52,900 --> 00:00:56,733

It is an official tool of Apple to install Windows system

12

00:00:57,666 --> 00:01:00,066

Its operation process is also very simple

13

00:01:00,333 --> 00:01:04,866

That is to enter bootcamp or boot conversion assistant in the Apple system

14

00:01:04,866 --> 00:01:07,133

Then there will be an interface like this

15

00:01:08,133 --> 00:01:11,566

We find the mirror file location under this interface

16

00:01:11,766 --> 00:01:16,133

Divide the partitions of Windows and Apple systems, and click Install

17

00:01:16,166 --> 00:01:20,566

Next, bootcamp will assist us in completing the Windows system installation process

18

00:01:21,900 --> 00:01:24,866

After the Windows system is installed, turn on this computer

19

00:01:24,866 --> 00:01:27,166

There will be a dvd drive inside

20

00:01:27,466 --> 00:01:30,200

Inside the DVD drive is the bootcamp

21

00:01:30,533 --> 00:01:34,333

Here I would like to remind everyone that the bootcamp software must be installed on the Apple computer

22

00:01:34,700 --> 00:01:36,800

to install the Windows system.

23

00:01:38,200 --> 00:01:42,133

The bootcamp software is used to install the driver under the Windows system

24

00:01:42,766 --> 00:01:44,700

Apple computer drivers are different

25

00:01:44,933 --> 00:01:48,366

Under normal circumstances, the use of third-party software may not be able to connect to the Apple driver,

26

00:01:48,766 --> 00:01:50,400

and you must use bootcamp.

27

00:01:53,300 --> 00:01:58,266

Finally, we should also note that the bootcamp in the Apple system is divided into several versions

28

00:01:58,533 --> 00:02:03,133

If you open bootcamp in the Mac system, it is not this interface

29

00:02:03,200 --> 00:02:08,600

Then we recommend directly using the Disk Utility partition plus PE installation method

30

00:02:10,800 --> 00:02:14,733

Let's look at Apple computers that only install Windows systems

31

00:02:14,933 --> 00:02:19,666

Apple computers only install Windows system, you need to prepare a PE disk and a software

32

00:02:19,666 --> 00:02:22,666

This software is the Apple version of the driver

33

00:02:24,166 --> 00:02:27,900

Apple computers only install Windows, and its process is relatively simple

34

00:02:28,200 --> 00:02:33,466

First of all, we need to know that Apple computers can also support PE startup.

35

00:02:33,966 --> 00:02:39,300

So the Windows PE disk we made before can also be used on Apple computers

36

00:02:39,733 --> 00:02:42,733

After booting, press option to enter the boot manager

37

00:02:42,866 --> 00:02:44,466

Select PE disk

38

00:02:44,466 --> 00:02:47,533

After entering PE, format the disk

39

00:02:47,733 --> 00:02:52,766

Be sure to pay attention when formatting, the partition table type should be in GUID format

40

00:02:53,333 --> 00:02:59,200

After the disk is formatted, the next steps are the same as installing Windows on a normal computer.

41

00:03:00,900 --> 00:03:03,166

It's just that after entering the system at last,

42

00:03:03,266 --> 00:03:07,133

you need to use the driver president apple version to install bootcamp

43

00:03:08,133 --> 00:03:13,166

Next, let's directly try to install the dual system using PE.

44

00:03:13,966 --> 00:03:15,800

First enter the Mac system

45

00:03:16,133 --> 00:03:17,900

Because we want to install dual systems,

46

00:03:17,933 --> 00:03:22,900

we must first enter the Apple system to partition the hard disk of the computer

47

00:03:23,100 --> 00:03:25,366

At this time, you need to use Disk Utility

48

00:03:26,400 --> 00:03:31,333

Click on the launchpad, click Disk Utility, and find the built-in disk

49

00:03:32,366 --> 00:03:34,066

Then we partition it

50

00:03:34,900 --> 00:03:36,000

Click partition

51

00:03:38,233 --> 00:03:40,066

Add a partition

52

00:03:40,066 --> 00:03:42,266

Add a 120G partition directly

53

00:03:42,533 --> 00:03:44,466

Then give it a name

54

00:03:46,366 --> 00:03:48,266

Let's call it Windows

55

00:03:48,900 --> 00:03:52,466

Format, you can choose, MacOS extended journal

56

00:03:56,133 --> 00:03:58,133

Click directly to apply

57

00:03:59,600 --> 00:04:01,166

Partition

58

00:04:04,400 --> 00:04:07,666

This time may be longer, we have to wait a little

59

00:04:15,400 --> 00:04:18,733

After partitioning, restart the computer directly

60

00:04:25,733 --> 00:04:31,800

Then plug in the PE disk, press option, and wait for it to enter the boot manager

61

00:04:35,000 --> 00:04:39,766

After entering the boot manager, you can see that the PE disk has been recognized

62

00:04:40,000 --> 00:04:43,600

Generally, a PE disk has only one startup item

63

00:04:44,766 --> 00:04:47,366

Because there are multiple systems in the PE disk

64

00:04:47,366 --> 00:04:50,566

So, it has three options here to choose from

65

00:04:51,166 --> 00:04:59,600

If your U disk also has multiple startup items, we can choose one by one to see which one can enter PE

66

00:05:00,566 --> 00:05:03,766

Now we are entering PE

67

00:05:07,266 --> 00:05:10,366

After entering PE, we open the partition wizard

68

00:05:10,966 --> 00:05:15,066

As you can see, the built-in hard disk is divided into two partitions

69

00:05:15,300 --> 00:05:19,066

One with APFS and the other without APFS

70

00:05:19,500 --> 00:05:23,466

Apple's system partition with APFS

71

00:05:23,700 --> 00:05:32,400

Let's format another partition and format it into NTFS format

72

00:05:42,933 --> 00:05:46,266

After the formatting is complete, we can start to install the system

73

00:05:46,500 --> 00:05:49,500

The operation process is the same as that of a normal computer

74

00:05:50,966 --> 00:05:53,366

We open the Windows installer

75

00:05:54,066 --> 00:05:59,566

In the first line, select the location of the ISO image, which is the location of the win 10 image

76

00:06:04,000 --> 00:06:06,300

The second line is better not to move

77

00:06:06,500 --> 00:06:09,766

The third line, select the disk after formatting

78

00:06:13,766 --> 00:06:18,600

Further down, the system version, the professional version, and the home version are all available

79

00:06:18,766 --> 00:06:21,566

Here we choose the professional version

80

00:06:22,766 --> 00:06:24,700

Then click Install and click OK

81

00:06:25,900 --> 00:06:27,766

Next it will walk a progress bar

82

00:06:29,200 --> 00:06:36,133

The speed of this progress bar may be relatively slow, let's fast forward it

83

00:06:39,300 --> 00:06:40,566

It's over now

84

00:06:40,566 --> 00:06:42,600

Click restart

85

00:06:43,566 --> 00:06:46,966

After restarting, it will start the second stage of the installation

86

00:06:47,266 --> 00:06:49,666

Here we just wait patiently

87

00:06:52,866 --> 00:06:54,966

Then enter the setting interface

88

00:06:55,066 --> 00:06:59,166

Here is the same as ordinary Windows, we just set it up

89

00:07:00,400 --> 00:07:04,400

After the setting is complete, you need to wait for a while

90

00:07:06,800 --> 00:07:09,933

Now it has entered the desktop of the Windows system

91

00:07:10,300 --> 00:07:12,100

Next, we will drive

92

00:07:12,266 --> 00:07:18,000

There is no driver now, so the network and the right button of the touchpad cannot be used

93

00:07:18,466 --> 00:07:22,133

We need to use the driver Apple version to drive

94

00:07:22,400 --> 00:07:24,600

This needs to be downloaded in advance,

95

00:07:25,300 --> 00:07:28,266

and it is downloaded in the same location as the ordinary driver.

96

00:07:30,366 --> 00:07:32,600

Open the driver Apple version in the U disk

97

00:07:40,700 --> 00:07:42,700

Well here it has matched a bootcamp

98

00:07:42,700 --> 00:07:44,966

Just one click to install

99

00:07:45,533 --> 00:07:50,500

The installation time of bootcamp will generally take a long time, we need to wait patiently

100

00:08:00,966 --> 00:08:02,866

Now bootcamp has been installed

101

00:08:03,200 --> 00:08:04,633

Next let's try

102

00:08:06,400 --> 00:08:11,266

Now you can connect to the Internet, and the two-finger right click on the touchpad can also be used

103

00:08:12,966 --> 00:08:15,733

All the devices in the device manager are also normal.

104

00:08:15,766 --> 00:08:17,933

Indicates that the driver has been installed

105

00:08:18,733 --> 00:08:21,000

Then the Windows system is already installed

106

00:08:21,133 --> 00:08:26,566

Finally, we switch back to the Apple system to try and see if the Apple system can still be used normally.

107

00:08:27,933 --> 00:08:29,133

Shutdown

108

00:08:34,666 --> 00:08:38,900

If you want to switch to the Apple system, you need to turn on the computer and press the option key

109

00:08:40,100 --> 00:08:41,733

It's turned off now

110

00:08:41,733 --> 00:08:44,500

We hold down the option key, then press the power button

111

00:08:51,666 --> 00:08:53,866

Let's unplug the u disk

112

00:08:56,100 --> 00:08:58,466

As you can see, there are now two boot partitions

113

00:08:58,500 --> 00:09:01,366

One is Windows and the other is Mac OS

114

00:09:01,566 --> 00:09:05,133

Let's go to Mac OS and try it out

115

00:09:07,066 --> 00:09:10,133

It can be seen that the Apple system can also be entered normally.

116

00:09:11,900 --> 00:09:16,766

At this point, the course of installing Windows system on Apple computers is over
